Description
The LASE 12LM-1000 12" Bass/Mid-Bass Speaker with 3" voice coil
The LASE 12LM-1000 features high efficiency and extended linearity. The radiator ensures efficient heat dissipation, allowing the user to power it to its max potential without fear of overheating. The aluminum voice coil provides a properly aligned Q factor and high sensitivity. Our specially designed shallow triple-roll surround guarantees low midrange distortion, and the fiberglass former voice coil, polycotton suspensions, and treated cone contribute to the LASE 12LM-1000's high power handling capability. When mounted in compact size bass reflex enclosures, the combination of a short voice coil, low mass, and suspension control makes the LASE 12LM-1000 an excellent choice for high power, 2-way satellite applications.The LASE 12LM-1000 is a popular replacement speaker for EAW, Yorkville, Sonic, Martin Audio, and other subwoofer speaker systems.
FEATURES
- Professional/Concert Touring Midbass Driver
- 3" Edgewound Aluminum Voice Coil on a fiberglass former
- 800 watt continuous Program Power Handling
- High Sensitivity and Low Distortion
- Shaped shallow triple-roll damped surround
- Primarily designed to be horn loaded in medium and long throw system
- Inverted dust cap minimizes cone distortion, improves coupling to a phase plug
SPECIFICATIONS
- Nominal Diameter: 12"
- Power Handling (rms): 400 watts
- Power Handling (max): 800 watts
- Impedance: 8 ohm
- Frequency Response: 50 to 3,000 Hz
- Maximum Linear Excursion (Xmax): 5mm
- Sensitiviy 101db 2.83/1 m
- Voice Coil Diameter : 3"
- Weight : 19 lbs / 8.61 kg.
