Description
The LASE NEO 15-1000MR - 15" MidBass Speaker 3" Voice Coil
The LASE NEO 15-1000MR features very high efficiency and extended linearity. The basket's radiator ensures ample heat dissipation. The aluminum voice coil provides a properly aligned Q factor and high sensitivity. The specially designed shallow triple-roll surround guarantees low midrange distortion, and a fiberglass former voice coil, polycotton suspensions, and treated cone contribute to the LASE NEO 15-1000 MR's very high power handling. When mounted in compact size bass reflex enclosures, the good combination of short voice coil, very low mass, and suspension control makes the LASE NEO 15-1000 MR an excellent choice for high power, 2-way satellite applications. The LASE NEO 15-1000 MR is a popular replacement speaker for EAW, Yorkville, Sonic, Martin Audio, and other subwoofer speaker systems.
FEATURES
- Professional/ Concert Touring Mid bass Driver.
- 3" Edgewound Aluminum voice coil on a fiber glass Former
- 500 watt continuous program power handling
- High Sensitivity and low distortion
- Shaped shallow triple-roll damped surround.
- Primarily designed to be horn loaded in medium and long throw system.
- Inverted dust cap minimizes cone distortion, improves coupling to a phase plug.
SPECIFICATIONS
- Nominal Diameter: 15"
- Power Handling: 500 W (rms)
- Power Handling: 900 W (max)
- Impedance: 8 ohm
- Frequency Response: 60 hz - 2,000 hz
- Sensitivity: 101 db 2.83/1m
- Voice Coil Diameter: 3"
- Weight: 11 lbs 7 oz (5.30 kgm)
