Description
Our LASE1201 replacement speaker for 12" Electro Voice speakers can be used in place of the following models:
- EVS-12SB
- EVM-12L
- Force 12
- SX200
- SX300
- EVI-12
- QRX
The LASE1201 speaker is recommended for use in professional audio as a sealed or vented midbass. It can also be used in a vented bass enclosure incorporating a high-pass filter and is great in horn-loaded designs thanks to its high motor strength.
FEATURES
- Professional bass/mid-bass speaker
- Polyamide-imide coated copper voice coil
- Kapton coil former
- 1000 watt continuous program power handling
- High sensitivity and low distortion
- Shaped shallow triple-roll damped surround
- Primarily designed to be horn loaded in medium and long throw system
- Ferrite magnet
SPECIFICATIONS
- Nominal Diameter: 12"
- Power Handling (rms): 500 watts
- Power Handling (max): 1000 watts
- Impedance: 8 ohm.
- Frequency Response: 57 to 2,800 Hz.
- Maximum Linear Excursion (Xmax): 4.8 mm
- Sensitivity: 97.1db 1w/1m
- Voice Coil Diameter: 3"
- Magnet Weight: 5 lbs
- Depth: 6"
